MIW03-24D15 The MINMAX MIW03-24D15 is a 3W DC-DC converter module in a DIP-24 package. It features a wide 2:1 input voltage range and fully regulated output.
Mfr Part #:

MIW03-24D15

Available from 1 distributors
Mfr Name: MINM
MINM
The MINMAX MIW03-24D15 is a 3W DC-DC converter module in a DIP-24 package. It features a wide 2:1 input voltage range and fully regulated output.
✓ Total Stock: 240 pcs

MIW03-24D15 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Husky International Electronic ✓
Non-Authorised Inventory information
240 pcs
On Request
240 pcs On Request 1 On Request On Request N/A On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

MIW03-24D15 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Efficiency
Industrial Grade
Lead Style
Mounting Type
Output Voltage
SVHC Present
View Similar Products (0)

MIW03-24D15 Description

Short technical summary and product information.

The MINMAX MIW03-24D15 is a high-performance DC-DC converter module designed for industrial applications. It comes in an industry-standard DIP-24 package, offering a wide 2:1 input voltage range of 18-36 VDC and a fully regulated 15 VDC output at 200 mA.



This converter boasts an efficiency of up to 85% and operates within an ambient temperature range of -40℃ to +85℃. It includes essential protection features such as under-voltage, overload, and short circuit protection. The I/O isolation is rated at 1500 VDC.



Typical applications for the MIW03 series include industrial electronics, instrumentation, and communication equipment where reliable power conversion is critical. The product meets EN 55032 Class A EMI emission standards and has safety approvals including UL/cUL/IEC/EN 62368-1.

MIW03-24D15 Quick Information

Product Type: DC-DC Converter
Series: MIW03
Canonical Name: MIW03-24D15 DC-DC Converter
Subcategory: DC-DC Converters

MIW03-24D15 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

MIW03-24D15 Features

  • Wide 2:1 input voltage range.
  • Fully regulated output voltage.
  • 1500 VDC I/O isolation.
  • Operating temperature range -40 to +85°C.
  • DIP-24 package for through-hole mounting.

MIW03-24D15 Applications

  • Board-mount power for distributed systems.
  • Isolated power for sensor interfaces.
  • Industrial control system power supply.
  • Telecommunications equipment isolation.

MIW03-24D15 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the input voltage range of the MIW03-24D15?

18-36 VDC.

What is the output voltage and current?

15 VDC at 200 mA.

What is the operating temperature range?

-40 to +85 °C (derate to 70 °C at full load).

What is the isolation voltage?

1500 VDC minimum.

What is the typical efficiency?

85%.

Does it have short circuit protection?

Yes, continuous with automatic recovery.

What is the package type?

DIP-24 through-hole.
