The Micrel Inc. MIC2208YML-TR is a high-efficiency PWM buck (step-down) regulator designed to provide up to 3A of output current. It operates at a 1MHz switching frequency and supports an adjustable output voltage down to 1V, with an input voltage range of 2.7V to 5.5V.
This regulator features external compensation for a closed-loop bandwidth over 100kHz and a low on-resistance internal p-channel MOSFET, contributing to efficiencies over 94%. It includes thermal shutdown and current limit protection, and operates within a junction temperature range of -40°C to +125°C.
The MIC2208YML-TR is supplied in a 12-pin 3mm x 3mm MLF package, suitable for surface mounting. Its design makes it ideal for applications such as 5V or 3.3V point-of-load conversion, telecom/networking equipment, set-top boxes, storage equipment, and video cards.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.08 | $1.08 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The input voltage range is 2.7V to 5.5V.
The output voltage is adjustable from 1V to 5.5V.
The junction temperature range is -40°C to +125°C.
The output current is 3A.
The switching frequency is 1MHz.
It is available in a 12-MLF (12-VFDFN Exposed Pad) surface-mount package.
Typical efficiency is greater than 90%.
