| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
31,103 pcs
|
31103 pcs | On Request | 1 | On Request | On Request | 2020+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| Fault Protection | |
| Features | |
| Input Type | |
| Interface | |
| Lead Style | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Configuration | |
| Output Type | |
| Ratio | |
| Rds On (Typ) | |
| SVHC Present | |
| Supplier Device Package | |
| Switch Type | |
| Voltage |
The MIC2042-2YM is a versatile power distribution switch designed for general-purpose power management applications. It features a high-side N-Channel MOSFET configuration, enabling it to switch voltages from 1.6V up to 5.5V.
Key electrical characteristics include a maximum continuous output current of 3A and a typical on-resistance of 40mOhm. The device offers adjustable current limiting, open load detection, over-temperature protection, and undervoltage lockout (UVLO) for robust fault protection. It also includes features like slew rate control and a fault status flag.
This power switch is housed in an 8-SOIC package, suitable for surface mount applications. Its design is optimized for applications requiring circuit protection and controlled power delivery, such as in docking stations, notebook PCs, and USB hosts.
The MIC2042-2YM provides essential protection and control for power rails, ensuring the safety of both the device and the connected load.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.32 | $0.32 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The part operates from 1.6V to 5.5V (minimum to maximum), with the datasheet specifying a wider range of 0.8V to 5.5V.
The maximum continuous output current is 3A.
The typical on-resistance is 40mOhm, with a maximum of 60mOhm.
It includes adjustable current limiting, open load detection, over-temperature protection, and undervoltage lockout (UVLO).
It is available in an 8-SOIC surface-mount package (0.154", 3.90mm width).
The ambient operating temperature range is -40°C to +85°C.
The output configuration is high-side N-channel with a 1:1 ratio.
