| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2 pcs
|
2 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Country of Origin | |
| Failure Rate | |
| Length | |
| Operating Pressure | |
| Port Size | |
| Product Type | |
| SVHC Present | |
| Temperature Range | |
| Weight |
The SMC MHC2-16S is a single-acting, 2-finger pneumatic gripper from the MHC series. It is designed for angle gripping applications and offers a bore size of 16mm. The gripper operates with a maximum pressure of 0.6 MPa and has a maximum operating frequency of 180 cycles per minute.
With a weight of 92g and a length of 25mm, this pneumatic gripper is suitable for various automation tasks. It operates within a temperature range of -10°C to 60°C. The port size is M5 x 0.8. The gripper is manufactured in Japan and complies with IEC 529 standards.
Additional product details indicate an operating pressure range of 1-6 bar and a temperature range of 0°C to 60°C. The opening angle is 30° when open and 10° when closed. The holding moment at 5 bar for the 16mm bore is 0.4Nm. Lubrication is not required for operation. The repeatability of the closing position is ±0.01mm.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.40 | $0.40 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The bore size is 16 mm.
It is an angle type gripper with single acting (spring return) operation.
The maximum operating pressure is 0.6 MPa.
The operating temperature range is 0°C to 60°C.
The weight is 92 grams.
The holding moment at 5 bar is 0.4 Nm for the 16mm bore size.
The repeatability is ±0.01 mm.
