| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Coil Current | |
| Coil Insulation | |
| Coil Type | |
| Coil Voltage | |
| Contact Form | |
| Contact Material | |
| Contact Rating (Current) | |
| Lead Style | |
| Mounting Type | |
| Must Operate Voltage | |
| Operate Time | |
| Operating Temperature | |
| Relay Type | |
| Release Time | |
| Switching Voltage | |
| Termination Style |
The Omron MGN2C-DC24 is a robust DPDT (2 Form C) power relay designed for demanding applications. It offers a substantial contact rating of 30 Amps and can switch up to 600VAC or 28VDC.
This relay operates on a 24VDC coil voltage with a non-latching type. It features a fast operate and release time of 30 ms, ensuring quick response in control circuits. The coil insulation is Class F, rated for 155°C, and molded in DuPont Rynite® for environmental protection.
Designed for chassis mounting, the MGN2C-DC24 utilizes convenient screw terminals for secure connections. Its operating temperature range is -40°C to 115°C, making it suitable for various environmental conditions. The relay also boasts a high electrical life expectancy of 100,000 operations at rated load and a mechanical life of 1,000,000 operations.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.00 | $2.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The Omron MGN2C-DC24 relay features a DPDT (2 Form C) contact form.
The contact rating for the Omron MGN2C-DC24 is 30 Amps.
The MGN2C-DC24 can switch up to 600VAC and 28VDC.
The coil voltage for the Omron MGN2C-DC24 is 24VDC.
The operating temperature range for the MGN2C-DC24 relay is -40°C to 115°C.
The MGN2C-DC24 relay uses chassis mount.
