| Category | |
| Manufacturer Name | |
| Coil Current | |
| Coil Insulation | |
| Coil Type | |
| Coil Voltage | |
| Contact Form | |
| Contact Rating (Current) | |
| Mounting Type | |
| Must Operate Voltage | |
| Operate Time | |
| Operating Temperature | |
| Relay Type | |
| Release Time | |
| Switching Voltage | |
| Termination Style |
The Omron MGN1X-AC12 is a general purpose relay designed for robust power applications. It features a Single Pole Single Throw Normally Open (SPST-NO) contact form, capable of handling a 30A current rating and switching voltages up to 600VAC or 28VDC.
The relay operates with a 12VAC coil, requiring a must-operate voltage of 10.2VAC. It offers a non-latching coil type and Class F coil insulation for enhanced thermal performance. The operate and release times are both rated at 30ms, ensuring efficient switching.
Designed for chassis mounting, the MGN1X-AC12 utilizes convenient screw terminals for secure connections. Its operating temperature range is -45°C to 80°C, making it suitable for various industrial environments. This relay is a reliable choice for applications requiring high current switching capabilities.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.00 | $2.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The Omron MGN1X-AC12 relay has a SPST-NO (DM) (1 Form X) contact form.
The maximum switching voltage for the MGN1X-AC12 relay is 600VAC and 28VDC.
The coil voltage for the Omron MGN1X-AC12 relay is 12VAC.
The operating temperature range for this relay is -45°C to 80°C.
The Omron MGN1X-AC12 relay is designed for chassis mounting.
