| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Medical Grade | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Package / Case | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The Bel Power Solutions MFLS250-1048 is an open frame AC/DC converter designed for medical applications. It delivers up to 250W of power with convection cooling and can reach 350W with forced air.
Key electrical specifications include a 48V output voltage, 7.2A current rating, and high efficiency up to 94%. The operating temperature range is -40°C to 70°C with derating. Features include adjustable output, DC input capability, PFC, and universal input.
This converter has a compact form factor with dimensions of 4.50" L x 2.50" W x 1.58" H. It is chassis mountable and meets standard 60601-1 for medical equipment.
Additional features include a 12V fan output, remote ON/OFF capability, PGPF signal, thermal shut-down, and dual fusing. It also offers optional current sharing and has a high MTBF of 800K hours.
The MFLS250-1048 has an output voltage of 4.38 kV.
The maximum current rating for the MFLS250-1048 is 7.2 A.
The MFLS250-1048 provides 250W of power with convection cooling and 346W with forced air.
The operating temperature range is -40°C to 70°C with derating.
The dimensions are 114.3mm (4.50") L x 63.5mm (2.50") W x 40.1mm (1.58") H.
The efficiency is up to 94%.
The MFLS250-1048 is suitable for medical applications.
