| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
227 pcs
|
227 pcs | On Request | 1 | On Request | On Request | N/A | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Efficiency | |
| Footprint | |
| Mounting Type | |
| Operating Temperature Range | |
| Output Current | |
| Output Voltage | |
| Package / Case | |
| Power | |
| SVHC Present |
The MINM MEW1000 series, including the MEW1022, offers 2W isolated DC-DC conversion in a compact SIP-9 package. These converters are designed for space-limited industrial and embedded applications, featuring a small footprint of 26 x 9.2 mm. The ultra-wide 4:1 input voltage range simplifies system design across varying DC bus conditions.
Key electrical specifications include a 1500 VDC I/O isolation voltage, fully regulated output, and protections against under-voltage, overload, and short circuits. The operating temperature range is -40℃ to +85℃, supported by excellent efficiency up to 80%.
These converters are certified to UL/cUL/IEC/EN 62368-1 safety standards, aiding in end-equipment compliance. The compact dimensions and robust features make the MEW1022 suitable for battery-powered equipment and instrumentation where PCB area is critical.
The MEW1022 supports input voltage ranges of 9-36 VDC and 18-75 VDC.
The MEW1000 series offers output voltages including 3.3 VDC, 5 VDC, 12 VDC, 15 VDC, ±5 VDC, ±12 VDC, and ±15 VDC.
The MEW1022 has a power rating of 2W.
The MEW1022 provides a minimum I/O isolation voltage of 1500 VDC.
The operating temperature range is -40 to +85 °C.
Yes, the MEW1022 features continuous short circuit protection with auto-recovery.
The MEW1000 series is certified to UL/cUL/IEC/EN 62368-1(60950-1) and has a CB-Report.
