The MEC1-120-02-S-D-A is a 1.00mm pitch mini edge card socket from Samtec's MEC1 series. It features a dual row design with 120 total positions, available in a vertical orientation with surface mount solder termination. The connector accepts 0.062" (1.57mm) thick PCBs and uses beryllium copper contacts with 30µin gold plating for reliable electrical performance.
Electrical ratings include 2.2A maximum current (2 pins powered) and 250 VAC / 354 VDC maximum voltage. The insulator is black liquid crystal polymer (LCP) rated for operating temperatures from -55°C to +125°C. A board guide feature aids alignment during assembly, and the connector is RoHS3 compliant (unverified).
This edge card socket is suitable for high-density board-to-board connections in industrial, telecommunications, and data communication systems. The surface mount package allows for automated pick-and-place assembly, and the dual readout design supports independent signal routing on both sides of the card.
| Qty | Low | High |
|---|---|---|
| 1+ | $6.98 | $6.98 |
| 10+ | $6.30 | $6.30 |
| 22+ | $5.67 | $5.67 |
| 44+ | $4.98 | $4.98 |
| 110+ | $4.60 | $4.60 |
| 264+ | $4.59 | $4.59 |
| 506+ | $4.25 | $4.25 |
| 1,012+ | $4.03 | $4.03 |
| 2,002+ | $3.87 | $3.87 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The part number indicates 120 positions (2 rows of 60), though the existing database lists 40 positions. Confirm for your application.
The pitch is 1.00mm (0.039 inches).
The maximum current rating is 2.2A (2 pins powered).
The maximum voltage rating is 250 VAC / 354 VDC.
Surface mount with solder termination.
Beryllium copper (BeCu) contacts with 30µin (0.76µm) gold plating.
