| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
36 pcs
|
36 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Style | |
| Connector Type | |
| Contact Type | |
| Features | |
| Flange Feature | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| SVHC Present | |
| Shell Material, Finish | |
| Shell Size, Connector Layout |
The ITT Cannon MDSM-25SC-Z11-VS1 is a Micro-D receptacle housing designed for use with female contacts. It offers 25 signal contact positions arranged in 2 rows, making it suitable for dense interconnect applications.
The housing features a steel shell with tin-nickel plating for durability and EMI shielding. It is designed for free hanging (in-line) mounting and includes a mating side flange with 2-56 threaded inserts for secure connection to a mating plug. The connector layout uses a 0.050 inch pitch with 0.100 inch row-to-row spacing.
This housing is part of the MDSM series and is supplied as a 5-piece kit. It is intended for use in applications requiring a rugged, shielded Micro-D connector interface.
| Qty | Low | High |
|---|---|---|
| 1+ | $21.71 | $21.71 |
| 10+ | $19.74 | $19.74 |
| 20+ | $19.13 | $19.13 |
| 50+ | $18.05 | $18.05 |
| 500+ | $16.14 | $16.14 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
25 positions.
Free hanging (in-line).
Yes, it is shielded.
Steel with tin-nickel plating.
0.050 inch pitch with 0.100 inch row-to-row spacing.
