This Delta Electronics MDS-065APS24 BA is an open frame AC/DC converter designed for ITE (Commercial) and Medical applications. It provides a single 24V output with a current rating of 2.7A, delivering a total power of 65W. The converter operates with a universal input voltage range of 90 to 264 VAC and boasts an efficiency of 85%.
Featuring a chassis mount type, this unit measures 101.6mm x 50.8mm x 30.5mm. It includes standby output functionality and an isolation voltage of 4 kV. The operating temperature range is from -10°C to 70°C. Compliance is indicated by agencies such as CB Scheme, CE, CQC, EN, and UL, with a RoHS3 compliant status.
Key specifications include a 2.7A output current and a 65W power capacity. The universal input makes it suitable for global use. The open frame construction is typical for integration into larger systems where space is a consideration.
The MDS-065APS24 BA provides a single 24V output at 2.7A.
The input voltage range is 90 to 264 VAC.
The operating temperature range is -10°C to 70°C.
The efficiency is 85%.
The isolation voltage is 4 kV.
The dimensions are 101.6mm x 50.8mm x 30.5mm (4.00" x 2.00" x 1.20").
It complies with standards including UL 60950-1, EN 62368-1, and IEC 60601-1.
