| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Industrial Grade | |
| Medical Grade | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| SVHC Present | |
| Standard Number | |
| Type | |
| Voltage |
This Delta Electronics MDS-065APS18 BA is an AC/DC converter with a power output of 65W and a voltage of 18V. It is designed as an Open Frame unit for Chassis Mount applications.
Key electrical specifications include an efficiency of 85% and a current output of 3.6A. The converter operates within a temperature range of -10°C to 70°C and offers isolation voltage of 4kV. It supports features such as Standby Output and Universal Input.
This model is approved by CB Scheme, CE, CQC, EN, and UL, and complies with standard numbers 50581, 55011, 55032, 60601-1, and 60950-1. It is suitable for ITE (Commercial) and Medical applications.
The physical dimensions are 101.6mm in length, 50.8mm in width, and 30.5mm in height.
18V at 3.6A.
65W.
85%.
4kV.
-10°C to 70°C.
Chassis mount.
ITE (Commercial) and Medical.
