| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2 pcs
|
2 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AC Voltage | |
| Applications | |
| Approval Agency | |
| Current | |
| DC Voltage | |
| Efficiency | |
| Features | |
| Height | |
| Industrial Grade | |
| Input Type | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Voltage | |
| Width |
The Mean Well MDR-20-15 is a 20W AC/DC DIN Rail power supply designed for industrial and commercial applications. It provides a single output of 15V at 1.34A, with an adjustable output feature allowing fine-tuning of the voltage. The unit accepts a universal AC input from 85 to 264 VAC, or DC input via 120V, making it versatile for various power systems.
With an efficiency of 81% and a 3kV isolation voltage, the MDR-20-15 ensures reliable and safe operation. It is approved by CB, CE, cULus, and TUV, and is RoHS3 and REACH compliant. The operating temperature range is -20°C to 70°C with derating, suitable for demanding environments.
The power supply is housed in a compact DIN Rail package measuring 100.0mm x 22.5mm x 90.0mm (3.94" x 0.89" x 3.54"), allowing for space-efficient installation in control cabinets. The DIN Rail mounting type simplifies integration into existing systems.
Designed for industrial and ITE (Commercial) applications, the MDR-20-15 is a reliable choice for powering controllers, sensors, and other automation equipment.
| Qty | Low | High |
|---|---|---|
| 1+ | $14.40 | $14.40 |
| 5+ | $13.80 | $13.80 |
| 10+ | $13.10 | $13.10 |
| 20+ | $12.80 | $12.80 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The AC input voltage range is 85 to 264 VAC, and DC input is 120V.
The output is 15V at 1.34A, with a maximum power of 20W. The output is adjustable.
The operating temperature range is -20°C to 70°C with derating.
The isolation voltage is 3 kV.
It is approved by CB, CE, cULus, and TUV.
It is a DIN Rail mount with dimensions 100.0mm x 22.5mm x 90.0mm (3.94" x 0.89" x 3.54").
The RoHS status is listed as RoHS3 Compliant, but this is unverified.
