| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2 pcs
|
2 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| 1st Connector | |
| 2nd Connector | |
| Color | |
| Contact Finish | |
| Contact Resistance | |
| Current Rating | |
| Durability | |
| Hardware | |
| Insulator Material | |
| Length | |
| Military Grade | |
| Number of Positions | |
| SVHC Present | |
| Shell Finish | |
| Shell Material | |
| Termination Style | |
| Type | |
| Wire Gauge |
This ITT Cannon Micro-D cable assembly, part number MDM-9SH016L, connects a 9-position D-Type, Micro-D receptacle with female sockets to individual 26 AWG color-coded wire leads. The cable length is 152.4 mm (6.00 inches). The receptacle features an aluminum shell with yellow chromate/cadmium over nickel finish and a low-profile jackscrew coupling. Contacts are gold plated copper alloy. The assembly is rated for 3 A maximum current and 600 VAC dielectric withstanding voltage at sea level. Insulation resistance is 5000 megohms minimum, and contact resistance is 8 milliohms maximum. The assembly is designed for rugged environments, withstanding thermal shock from -55°C to +125°C, physical shock of 50 G's, and vibration of 20 G's. It is rated for a minimum of 500 mating cycles and 48 hours of salt spray exposure. The terminations are 6-inch minimum, M16874/4 #26AWG, color coded wire leads.
This assembly is suitable for military, aerospace, and industrial applications requiring a reliable, high-density interconnect. The Micro-D series offers a compact, metal-shell connector with proven durability.
The cable length is 0.500' (152.40mm, 6.00").
D-Type, Micro-D receptacle with female sockets, 9 positions.
3 A maximum.
-55°C to +125°C.
Gold.
6" Min, M16874/4 #26AWG, Colored Code (individual wire leads).
Aluminum shell with Yellow Chromate/Cadmium over Nickel finish.
