| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
14 pcs
|
14 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request | |
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Style | |
| Connector Type | |
| Contact Finish | |
| Contact Material | |
| Contact Resistance | |
| Contact Type | |
| Coupling | |
| Current Rating (Amps) | |
| Dielectric Withstanding Voltage (Minimum @ At 70,000 ft altitude) | |
| Dielectric Withstanding Voltage (Minimum @ At sea level) | |
| Durability | |
| Features | |
| Flange Feature | |
| Hardware | |
| Insulator Material | |
| Insulator Resistance | |
| Moisture Resistance | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Physical Shock | |
| Salt Spray | |
| Shell Material, Finish | |
| Shell Size, Connector Layout | |
| Termination | |
| Termination Type | |
| Thermal Shock | |
| Vibration |
The ITT Cannon MDM-9PCBRP is a 9-position Micro-D plug connector from the MICRO series, designed for reliable signal interconnections in demanding environments. It features a D-Type, Micro-D shell style with a plug, male pin contact arrangement. The connector is panel mounted with through hole, right angle solder terminations, making it suitable for compact PCB layouts.
Electrical specifications include a maximum current rating of 3 A, contact resistance of 8 mΩ maximum, and dielectric withstanding voltage of 600 VAC at sea level and 150 VAC at 70,000 ft altitude. The insulator resistance is a minimum of 5000 MΩ. The contacts are gold plated copper alloy, ensuring low resistance and corrosion resistance.
The shell is aluminum with yellow chromate plated cadmium finish, providing shielding and durability. The connector includes a jackscrew coupling mechanism and female screwlock (2-56) flange feature for secure mating. It is rated for 500 mating cycles and can withstand thermal shock from -55°C to +125°C, physical shock of 50 G's, and vibration of 20 G's.
| Qty | Low | High |
|---|---|---|
| 1+ | $149.63 | $149.63 |
| 50+ | $122.69 | $122.69 |
| 100+ | $109.61 | $109.61 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The MDM-9PCBRP has 9 positions arranged in 2 rows.
The maximum current rating is 3 A.
It is panel mount with through hole, right angle solder termination.
The contacts are gold plated copper alloy.
Yes, it features a shielded aluminum shell with yellow chromate plated cadmium finish.
