| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
25 pcs
|
25 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Style | |
| Connector Type | |
| Contact Finish | |
| Contact Type | |
| Current Rating (Amps) | |
| Features | |
| Flange Feature | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Shell Material, Finish | |
| Shell Size, Connector Layout | |
| Termination | |
| Termination Style |
The ITT Cannon MDM-25PCBRP is a D-Type Micro-D connector featuring a plug with male pins in a 25-position, 3-row configuration. It is designed for panel mount and through-hole mounting with a right-angle solder termination style, making it suitable for applications where space is constrained and a low-profile connection is required.
This connector is rated for 3A current per contact and features gold-plated signal contacts for reliable low-level signal transmission. The shell is constructed from aluminum with a yellow chromate plated cadmium finish, providing durability and corrosion resistance. A mating side female screwlock (2-56) flange feature ensures secure mating.
The connector is shielded for EMI protection and uses a 0.050 inch pitch with 0.100 inch row-to-row spacing. It is suitable for use in military, aerospace, and industrial applications where high-reliability interconnects are required.
| Qty | Low | High |
|---|---|---|
| 1+ | $310.75 | $310.75 |
| 10+ | $292.14 | $292.14 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It is a Plug, Male Pins connector in a D-Type, Micro-D style.
It has 25 positions arranged in 3 rows.
It is panel mount and through hole with a right angle orientation, terminated by solder.
Each contact is rated for 3A.
The contacts have a gold finish.
Yes, it features shielding.
The shell is aluminum with a yellow chromate plated cadmium finish.
