| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Power (Watts) | |
| Stability | |
| Temperature Coefficient | |
| Type | |
| Voltage | |
| Width |
This MD24-4.8-A from SL Power Electronics is a linear AC DC converter designed for various applications, including medical. It operates with a universal input voltage range of 100 to 240 VAC and provides a stable 24V DC output at up to 4.8A, totaling 115W of power.
The converter boasts an efficiency of 60% and features like adjustable output and remote sensing for enhanced design flexibility. It is designed for chassis mounting and operates within a temperature range of 0°C to 70°C with derating.
Key specifications include line and load regulation of ±0.05%, an output ripple of 3 mV +0.05% peak to peak maximum, and a transient response under 50 microseconds for a 50% load change. It also includes automatic current limit/foldback for short circuit protection.
Compliance includes CE, cURus, and TUV approvals. The unit is RoHS3 compliant and has an MSL rating of 1.
The input voltage range is 100 to 240 VAC.
The output is 24V DC at 4.8A, providing 115W of power.
The operating temperature range is 0°C to 70°C with derating.
It features automatic current limit/foldback short circuit protection.
The efficiency is 60%.
The dimensions are 228.6mm L x 124.0mm W x 69.9mm H.
