MCZ33903D5EK The NXP Semiconductors MCZ33903D5EK is a System Basis Chip featuring CAN and LIN interfaces. It operates within a voltage range of 5.5V to 28V and is housed in a 32-SOIC-EP package.
Mfr Part #:

MCZ33903D5EK

Available from 1 distributors
Mfr Name: NXP Semiconductors
NXP Semiconductors
The NXP Semiconductors MCZ33903D5EK is a System Basis Chip featuring CAN and LIN interfaces. It operates within a voltage range of 5.5V to 28V and is housed in a 32-SOIC-EP package.
✓ Total Stock: 7,224 pcs
$ Price Range: $6.39

MCZ33903D5EK Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Flip Electronics ✓
Non-Authorised Inventory information
7,224 pcs
On Request
7224 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

MCZ33903D5EK Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Applications
Interface
Lead Spacing
Mounting Type
Quiescent Current
Supplier Device Package
Technology
Voltage
View Similar Products (0)

MCZ33903D5EK Description

Short technical summary and product information.

The NXP Semiconductors MCZ33903D5EK is a second-generation System Basis Chip (SBC) designed for advanced power management in MCU applications. It integrates features such as high-speed CAN (ISO11898-2 and -5) and LIN 2.1 interfaces, along with multiple wake-up sources and low-power modes for reduced current consumption.



This device offers robust protection features including voltage, current, and temperature monitoring. It includes a fully protected embedded 5.0 V regulator for the CAN driver and an auxiliary SPI configurable regulator (5.0 or 3.3 V) for additional ICs. The SBC supports baud rates from 40 kb/s to 1.0 Mb/s for its CAN interface and can accommodate zero, one, or two LIN interfaces.



Designed with SMARTMOS technology, the MCZ33903D5EK is suitable for various automotive and industrial applications. It is available in a 32-SOIC-EP package, supporting surface mount installation. The chip also provides advanced diagnostics for SPI, MCU, ECU power supply, and critical pins, enhancing system reliability.



Key specifications include a wide operating voltage range of 5.5V to 28V and multiple undervoltage detection capabilities. The device also features an innovative fail-safe state machine and concept solution, making it a versatile component for complex electronic systems.

MCZ33903D5EK Quick Information

Product Type: System Basis Chip
Canonical Name: System Basis Chip with CAN and LIN Interface
Subcategory: System Basis Chip

MCZ33903D5EK Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

MCZ33903D5EK Estimated Pricing

Qty Low High
1+ $6.39 $6.39

Estimated market price range - modelled values for guidance only, not live distributor offers.

MCZ33903D5EK Features

  • Second-generation System Basis Chip (SBC).
  • High-speed CAN and LIN interfaces integrated.
  • Wide operating voltage from 5.5V to 28V.
  • Multiple low-power modes with low current.
  • Advanced protection and diagnostic features.

MCZ33903D5EK Applications

  • Automotive and robotic systems.
  • Industrial actuator controls.
  • Lamp and inductive load controls.
  • DC motor control applications.
  • Aircraft and marine systems.

MCZ33903D5EK FAQs

6 frequently asked questions generated from this part’s specifications.
What is the operating voltage range for the MCZ33903D5EK?

The operating voltage range is 5.5V to 28V.

What type of package is the MCZ33903D5EK in?

The MCZ33903D5EK is available in a 32-SOIC-EP package and a 32-SSOP (0.295", 7.50mm Width) Exposed Pad package.

What are the interface types supported by the MCZ33903D5EK?

The MCZ33903D5EK supports CAN and LIN interfaces.

What are the primary applications for the MCZ33903D5EK?

The primary application for the MCZ33903D5EK is as a System Basis Chip.

Does the MCZ33903D5EK have low-power modes?

Yes, this device implements multiple Low-power (LP) modes with very low-current consumption.

What protection features are included in the MCZ33903D5EK?

The MCZ33903D5EK includes voltage, current, and temperature protection.
