| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2 pcs
|
2 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Current | |
| Industrial Grade | |
| Input Logic Level | |
| Lead Spacing | |
| Lead Style | |
| Logic Type | |
| Max Propagation Delay @ V, Max CL | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Circuits | |
| Number of Inputs | |
| Operating Temperature | |
| Supplier Device Package | |
| Voltage |
The MC74HC20D is a dual 4-input NAND gate IC manufactured by On Semiconductor. This logic gate operates within a voltage range of 2V to 6V, making it suitable for various digital applications. It offers a maximum propagation delay of 15ns when operating at 6V with a 50pF load capacitance.
Designed for surface mounting, the MC74HC20D comes in a 14-SOIC package with a width of 0.209 inches (5.30mm). The operating temperature range is from -55°C to 125°C. This component is part of the HC logic family, known for its high noise immunity and speed.
Key electrical characteristics include an input logic level range of 1.5V to 4.2V and a typical current draw of 5.2mA. The device contains two independent 4-input NAND gates, providing flexibility in circuit design.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.22 | $0.22 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
2V to 6V.
14-SOIC (0.209", 5.30mm Width).
-55°C to 125°C.
NAND Gate.
4 inputs per gate.
2 circuits.
15ns at 6V, 50pF.
