MC56F8357VPYE The NXP Semiconductors MC56F8357VPYE is a 16-bit microcontroller with 256KB of FLASH program memory and 10KB of RAM. It operates at speeds up to 60MHz.
Mfr Part #:

MC56F8357VPYE

Available from 3 distributors
Mfr Name: NXP Semiconductors
NXP Semiconductors
The NXP Semiconductors MC56F8357VPYE is a 16-bit microcontroller with 256KB of FLASH program memory and 10KB of RAM. It operates at speeds up to 60MHz.
✓ Total Stock: 15,429 pcs
$ Price Range: $6.40

MC56F8357VPYE Available from 3 distributors

✓ Authorised
✓ Non-Authorised
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

MC56F8357VPYE Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connectivity
Core Processor
Core Size
Data Converters
Lead Spacing
Mounting Type
Number of I
Operating Temperature
Oscillator Type
Peripherals
Program Memory Size
Program Memory Type
RAM Size
Speed
Supplier Device Package
Voltage
View Similar Products (0)

MC56F8357VPYE Description

Short technical summary and product information.

This NXP Semiconductors microcontroller, part number MC56F8357VPYE, is a 16-bit device designed for embedded applications. It features 256KB of FLASH program memory and 10KB of RAM, operating at a maximum speed of 60MHz.



The device supports a wide operating voltage range of 2.25V to 3.6V and operates within a temperature range of -40°C to 105°C (TA). It includes peripherals such as POR, PWM, Temperature Sensor, and WDT, along with data conversion capabilities via a 16-channel, 12-bit A/D converter.



Connectivity options include CANbus, EBI/EMI, SCI, and SPI. The microcontroller is housed in a 160-LQFP package suitable for surface mounting. It offers 76 I/O lines for interfacing with other components.



This component is RoHS3 compliant and has a Moisture Sensitivity Level (MSL) of 1 Unlimited. It is designed for reliable performance in various industrial and embedded systems.

MC56F8357VPYE Quick Information

Product Type: Microcontroller
Canonical Name: MC56F8357VPYE Microcontroller
Subcategory: Microcontrollers

MC56F8357VPYE Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

MC56F8357VPYE Estimated Pricing

Qty Low High
1+ $6.40 $6.40

Estimated market price range - modelled values for guidance only, not live distributor offers.

MC56F8357VPYE Features

  • 16-bit 56800E core processor.
  • 256KB FLASH program memory.
  • 10KB internal RAM.
  • 60MHz operating speed.
  • 160-LQFP surface mount package.

MC56F8357VPYE Applications

  • Suitable for embedded control systems.
  • Ideal for applications requiring CANbus communication.
  • Used in systems needing SPI or SCI interfaces.
  • Designed for wide voltage range operation.

MC56F8357VPYE FAQs

4 frequently asked questions generated from this part’s specifications.
What is the operating voltage for the MC56F8357VPYE?

The operating voltage is between 2.25V and 3.6V.

What package type is the MC56F8357VPYE microcontroller supplied in?

The microcontroller is supplied in a 160-LQFP package.

What is the operating temperature range for this microcontroller?

The operating temperature range is -40°C to 105°C (TA).

Is the MC56F8357VPYE RoHS compliant?

Yes, it is RoHS3 compliant.
