MC34932SEK The NXP Semiconductors MC34932SEK is a 4-channel half-bridge driver IC designed for motor control applications. It features a 5A current capability and operates from 5V to 36V.
Mfr Part #:

MC34932SEK

Available from 1 distributors
Mfr Name: NXP Semiconductors
NXP Semiconductors
The NXP Semiconductors MC34932SEK is a 4-channel half-bridge driver IC designed for motor control applications. It features a 5A current capability and operates from 5V to 36V.
✓ Total Stock: 598 pcs
$ Price Range: $2.25

MC34932SEK Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Flip Electronics ✓
Non-Authorised Inventory information
598 pcs
On Request
598 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

MC34932SEK Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Applications
Current
Function
Interface
Motor Type
Mounting Type
Operating Temperature
Output Configuration
SVHC Present
Supplier Device Package
Technology
Voltage
View Similar Products (0)

MC34932SEK Description

Short technical summary and product information.

The MC34932SEK from NXP Semiconductors is an integrated half-bridge driver IC, suitable for controlling DC motors and DC servo motors. This device integrates control and power stages, simplifying system design.



Key electrical specifications include an operating voltage range of 5V to 36V and a current handling capability of 5A. The operating temperature range is from -40°C to 150°C (TJ). The interface is logic-level compatible.



This component is housed in a 54-SOIC-EP package with an exposed pad and is designed for surface mount applications. It is described as RoHS3 compliant and is a green, environmentally friendly, lead-free product.



The MC34932SEK is designed for general-purpose motor driver applications, offering a robust solution for power management in various industrial systems.

MC34932SEK Quick Information

Product Type: Motor Driver IC
Canonical Name: MC34932SEK Half-Bridge Driver IC
Subcategory: Motor Driver

MC34932SEK Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: green and environmentally friendly lead-free product

MC34932SEK Estimated Pricing

Qty Low High
1+ $2.25 $2.25

Estimated market price range - modelled values for guidance only, not live distributor offers.

MC34932SEK Features

  • Integrated half-bridge driver for 4 channels.
  • Operates from 5V to 36V supply voltage.
  • Handles up to 5A of current.
  • Wide operating temperature range of -40°C to 150°C.
  • Surface mountable in 54-SOIC-EP package.

MC34932SEK Applications

  • Suitable for DC motor control.
  • Used in DC servo motor applications.
  • General purpose motor driving.
  • Integrated power and control stages.

MC34932SEK FAQs

6 frequently asked questions generated from this part’s specifications.
What is the operating voltage range of the MC34932SEK?

5V to 36V

What is the package type of the MC34932SEK?

54-SSOP (0.295", 7.50mm Width) Exposed Pad

What is the operating temperature range?

-40°C to 150°C (TJ)

What is the maximum continuous output current?

5A

What output configuration does the MC34932SEK provide?

Half Bridge (4)

What motor types are supported?

Brushed DC, DC Servo
