| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,040 pcs
|
1040 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Mounting Type | |
| Number of Regulators | |
| Operating Temperature | |
| SVHC Present | |
| Supplier Device Package | |
| Voltage |
The MC34704AEP is a multi-channel Power Management IC (PMIC) from NXP Semiconductors, designed to meet the power management needs of multimedia application microprocessors. It offers the flexibility of providing up to 8 independent output voltages from a single input power supply ranging from 2.7V to 5.5V, making it suitable for portable devices powered by Li-Ion/polymer batteries or USB-powered applications.
This device operates at a switching frequency of up to 2.0 MHz, enabling the use of smaller external components and facilitating space-efficient power management solutions. Key features include up to ±2% output voltage accuracy, dynamic voltage scaling, and I2C programmability. It also incorporates essential protection features such as output undervoltage/overvoltage detection, overcurrent limit detection, and thermal limit detection for most regulators.
Housed in a 7x7 mm, Pb-free, 56-QFN-EP package, the MC34704AEP is designed for surface mounting. Its SMARTMOS technology ensures high efficiency and reliable performance for demanding applications.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.75 | $0.75 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The MC34704AEP offers 8 DC/DC switching regulators.
The output voltage accuracy is up to ±2%.
The maximum switching frequency is 2.0 MHz.
The operating voltage range is 2.7V to 5.5V.
The operating temperature range is -20°C to 85°C.
The MC34704AEP is housed in a 56-QFN-EP (7x7) package, also described as a 56-VFQFN Exposed Pad.
The MC34704AEP is a surface mount device.
