MC33363AP The ON Semiconductor MC33363AP is a high voltage switching regulator designed for offline power supplies. It features an integrated 700V/1.5A power switch and operates from a 9.5V to 40V supply.
Mfr Part #:

MC33363AP

Available from 1 distributors
Mfr Name: On Semiconductor
On Semiconductor
The ON Semiconductor MC33363AP is a high voltage switching regulator designed for offline power supplies. It features an integrated 700V/1.5A power switch and operates from a 9.5V to 40V supply.
✓ Total Stock: 5,000 pcs
$ Price Range: $0.75

MC33363AP Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Components Technology Group, Inc. ✓
Non-Authorised Inventory information
5,000 pcs
On Request
5000 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

MC33363AP Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Control Features
Duty Cycle
Fault Protection
Frequency
Internal Switch(s)
Lead Spacing
Mounting Type
Operating Temperature
Output Isolation
SVHC Present
Supplier Device Package
Topology
Voltage
View Similar Products (0)

MC33363AP Description

Short technical summary and product information.

The MC33363AP from ON Semiconductor is a monolithic high voltage switching regulator designed for operation from rectified 240 Vac line sources. This integrated circuit incorporates a 700 V / 1.5 A SENSEFET power switch and a 500 V active off-line startup FET.



Key features include a duty cycle controlled oscillator, current limiting comparator with programmable threshold and leading edge blanking, and a latching pulse width modulator for double pulse suppression. Protective features such as cycle-by-cycle current limiting, input undervoltage lockout with hysteresis, output overvoltage protection, and thermal shutdown are integrated into the device.



This regulator operates with a supply voltage range of 9.5V to 40V and features a switching frequency range of 67.5kHz to 285kHz. The MC33363AP is available in a 16-lead dual-in-line (DIP) package, suitable for through-hole mounting.



Its topology supports Flyback and Forward configurations, and the output is isolated. The device is designed for applications requiring efficient and reliable offline power conversion.

MC33363AP Quick Information

Product Type: Switching Regulator
Canonical Name: MC33363A High Voltage Switching Regulator
Subcategory: Power Management (PMIC)

MC33363AP Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

MC33363AP Estimated Pricing

Qty Low High
1+ $0.75 $0.75

Estimated market price range - modelled values for guidance only, not live distributor offers.

MC33363AP Features

  • Integrated 700V, 1.5A SENSEFET power switch.
  • Operates from rectified 240 Vac line source.
  • Includes 500V active off-line startup FET.
  • Cycle-by-cycle current limiting protection.
  • Available in a 16-DIP through-hole package.

MC33363AP Applications

  • Designed for offline switching regulators.
  • Suitable for 240 Vac line source operation.
  • Used in Flyback and Forward converter topologies.
  • Provides isolated power output.

MC33363AP FAQs

7 frequently asked questions generated from this part’s specifications.
What is the maximum drain voltage for the power switch?

The maximum drain voltage for the power switch is 700 V.

What is the maximum continuous drain current?

The maximum continuous drain current is 1.5 A.

What is the operating supply voltage range?

The operating supply voltage range is 9.5 V to 40 V.

What is the operating temperature range?

The operating temperature range is -25°C to 150°C (TJ).

What package is the MC33363AP available in?

The MC33363AP is available in a 16-DIP (0.300", 7.62mm) package.

What fault protection features are included?

Fault protection includes Current Limiting, Over Temperature, and Over Voltage.

What topologies does this switching regulator support?

This switching regulator supports Flyback and Forward topologies.
