MC20902 The METICOM MC20902 is an FPGA bridge IC designed for MIPI D-PHY systems, facilitating LVDS to SLVS conversion. It supports high-speed data rates up to 2.5 Gbps.
Mfr Part #:

MC20902

Available from 1 distributors
Mfr Name: METICOM
METICOM
The METICOM MC20902 is an FPGA bridge IC designed for MIPI D-PHY systems, facilitating LVDS to SLVS conversion. It supports high-speed data rates up to 2.5 Gbps.
✓ Total Stock: 2,049 pcs

MC20902 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Optech Co.,Limited ✓
Non-Authorised Inventory information
2,049 pcs
On Request
2049 pcs On Request 1 On Request On Request 24+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

MC20902 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Package / Case
Pitch
SVHC Present
View Similar Products (0)

MC20902 Description

Short technical summary and product information.

The MC20902 from Meticom is a high-performance FPGA bridge IC specifically engineered for MIPI D-PHY systems. It excels at converting LVDS to SLVS signals, making it suitable for various interface applications. This device supports a high-speed (HS) mode data rate of up to 2.5 Gbps and a low-power data transmission (LPDT) mode data rate of up to 20 Mbps.



The MC20902 is designed to seamlessly integrate into systems requiring MIPI D-PHY compliance, including those utilizing DSI, CSI-1, and CSI-2 standards. Its functionality extends to converting SLVS input signals to LVDS output data streams, offering flexibility in system design. The IC is available in a compact VQFN-16-4 package measuring 3mm x 3mm x 0.9mm with a 0.5mm pitch, suitable for space-constrained applications.



Key features include automatic switching of D-PHY termination based on HS or LP mode, eliminating the need for additional level shifters. This ensures efficient and reliable signal conversion. The MC20902 is an ideal component for designers working with high-speed data interfaces and MIPI D-PHY compliant systems.

MC20902 Quick Information

Product Type: FPGA Bridge IC
Canonical Name: MC20902 FPGA Bridge IC for MIPI D-PHY Systems and LVDS to SLVS Conversion
Subcategory: MIPI D-PHY Systems and LVDS to SLVS Conversion

MC20902 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

MC20902 Features

  • FPGA bridge IC for MIPI D-PHY systems
  • Converts LVDS to SLVS signals
  • Supports up to 2.5 Gbps HS mode data rate
  • Supports up to 20 Mbps LPDT mode data rate
  • Available in VQFN-16-4 package

MC20902 Applications

  • Ideal for MIPI D-PHY interfaces
  • Suitable for DSI applications
  • Used in CSI-1 and CSI-2 systems
  • Facilitates LVDS to SLVS conversion

MC20902 FAQs

6 frequently asked questions generated from this part’s specifications.
What is the maximum data rate in HS mode?

2.5 Gbps.

What is the data rate in LPDT mode?

20 Mbps.

What is the data rate for SLVS input to LVDS output?

2.5 Gbps.

What is the package type?

VQFN-16-4.

What are the package dimensions?

3mm x 3mm x 0.9mm.

What is the pitch?

0.5mm.
