| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Duration | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Power (Watts) | |
| Stability | |
| Storage Temperature | |
| Temperature Coefficient | |
| Type | |
| Voltage | |
| Width |
This linear AC DC converter from SL Power Electronics, part number MC12-3.4-A, is designed for reliable power conversion in various applications, particularly those requiring medical-grade specifications. It accepts a universal input voltage range of 100 to 240 VAC and delivers a stable 12V DC output with a current capacity of 3.4A, totaling 41W of power.
The unit offers an efficiency of 55% and operates within a temperature range of 0°C to 70°C, with derating applied at higher temperatures. Key electrical specifications include line and load regulation of ±0.05%, and output ripple of 3mV +0.05% peak to peak maximum. It also features automatic current limit/foldback for short circuit protection and optional overvoltage protection on some models.
Designed for easy integration, the MC12-3.4-A utilizes a chassis mount for secure installation. Its dimensions are 143.0mm x 124.0mm x 63.5mm. The converter is approved by CE, cURus, and TUV, and meets FCC and CISPR22 Class B conducted emissions standards, making it suitable for demanding environments. It also includes features like remote sensing for improved output accuracy and universal input for global compatibility.
100-240 VAC.
12V DC.
3.4 A.
55%.
0°C to 50°C full rated, derated linearly to 40% at 70°C.
Chassis mount.
Automatic current limit/foldback.
