MC100ELT25D The MC100ELT25D is a differential ECL to TTL translator from N-A. It features a typical propagation delay of 2.6 ns and a maximum clock frequency of 100 MHz.
Mfr Part #:

MC100ELT25D

Available from 1 distributors
Mfr Name: N-A
N-A
The MC100ELT25D is a differential ECL to TTL translator from N-A. It features a typical propagation delay of 2.6 ns and a maximum clock frequency of 100 MHz.
✓ Total Stock: 425 pcs

MC100ELT25D Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Husky International Electronic ✓
Non-Authorised Inventory information
425 pcs
On Request
425 pcs On Request 1 On Request On Request N/A On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

MC100ELT25D Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Lead Spacing
Lead Style
Output Current
Package / Case
Propagation Delay
SVHC Present
Tape & Reel
View Similar Products (0)

MC100ELT25D Description

Short technical summary and product information.

The MC100ELT25D is a differential ECL to TTL translator designed for applications requiring space, performance, and low power. It operates with a VCC range of 4.5 V to 5.5 V and a VEE range of -4.2 V to -5.7 V.



Key electrical characteristics include a typical propagation delay of 2.6 ns and a maximum clock frequency (FMAX CLK) of 100 MHz. The device offers TTL outputs capable of 24 mA. It also features internal 50 kΩ pulldown resistors on the inputs and ESD protection exceeding 1 kV for the Human Body Model and 400 V for the Machine Model.



This translator is available in an 8-lead SOIC package. The MC100ELT25D is part of the MC10ELT25/MC100ELT25 series, known for its temperature compensation in the 100 Series. The device is suitable for applications where ECL levels need to be converted to TTL levels efficiently.

MC100ELT25D Quick Information

Product Type: Translator
Series: MC100ELT
Canonical Name: MC100ELT25D Differential ECL to TTL Translator
Subcategory: Level Shifter

MC100ELT25D Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): Level 1
REACH Status: REACH Unaffected

MC100ELT25D Features

  • Differential ECL to TTL translator.
  • 2.6 ns typical propagation delay.
  • 100 MHz maximum clock frequency.
  • 24 mA TTL outputs.
  • 8-lead SOIC package.

MC100ELT25D Applications

  • High-speed clock and data translation.
  • Telecommunications and networking equipment.
  • Interface between PECL and TTL logic families.
  • Signal level shifting in mixed-voltage systems.

MC100ELT25D FAQs

7 frequently asked questions generated from this part’s specifications.
What is the operating voltage range for the MC100ELT25D?

VCC operates from 4.5 V to 5.5 V and VEE operates from -4.2 V to -5.7 V.

What package does the MC100ELT25D come in?

The MC100ELT25D is available in an SOIC-8 package.

What is the propagation delay of the MC100ELT25D?

Typical propagation delay is 2.6 ns.

What is the maximum clock frequency of the MC100ELT25D?

Typical maximum clock frequency is 100 MHz.

What is the output current capability of the MC100ELT25D?

Typical output current is 24 mA.

What ESD protection does the MC100ELT25D have?

ESD protection is >1 kV (Human Body Model) and >400 V (Machine Model).

How many transistors are in the MC100ELT25D?

The device contains 38 transistors.
