MC08XS6421CEKR2 The NXP Semiconductors MC08XS6421CEKR2 is a dual high-side switch featuring low on-resistance and flexible SPI control. It operates from 7.08V to 18V and offers robust fault protection.
Mfr Part #:

MC08XS6421CEKR2

Available from 1 distributors
Mfr Name: NXP Semiconductors
NXP Semiconductors
The NXP Semiconductors MC08XS6421CEKR2 is a dual high-side switch featuring low on-resistance and flexible SPI control. It operates from 7.08V to 18V and offers robust fault protection.
✓ Total Stock: 42,000 pcs
$ Price Range: $0.32

MC08XS6421CEKR2 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Flip Electronics ✓
Non-Authorised Inventory information
42,000 pcs
On Request
42000 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

MC08XS6421CEKR2 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Current
Fault Protection
Input Type
Interface
Mounting Type
Number of Outputs
Operating Temperature
Output Configuration
Output Type
Ratio
Rds On (Typ)
Supplier Device Package
Switch Type
Voltage
View Similar Products (0)

MC08XS6421CEKR2 Description

Short technical summary and product information.

The MC08XS6421CEKR2 from NXP Semiconductors is a dual high-side switch designed for automotive lighting applications. It offers two channels with 8.0 mOhm resistance and two channels with 21 mOhm resistance, providing flexibility for various load types.



This device supports a wide operating voltage range from 7.08V to 18V, with an extended mode from 6.08V to 28V. It features a 16-bit, 5.0 MHz SPI interface for control and diagnostics, including overcurrent profiles, output monitoring, and fault reporting. Protection features include current limiting, open load detection, and thermal shutdown.



The MC08XS6421CEKR2 is available in a 54-SSOP exposed pad package, suitable for surface mounting. Its design facilitates ECU integration with compatible MCU software and PCB footprints within the 12XS6 family.



Key electrical characteristics include a sleep current below 5.0 µA and protection against -16V reverse polarity and ground disconnect. The switch type is general purpose with N-Channel output configuration.

MC08XS6421CEKR2 Quick Information

Product Type: Power Distribution Switch
Series: 12XS6
Canonical Name: Dual High-Side Switch
Subcategory: Load Driver

MC08XS6421CEKR2 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

MC08XS6421CEKR2 Estimated Pricing

Qty Low High
1+ $0.32 $0.32

Estimated market price range - modelled values for guidance only, not live distributor offers.

MC08XS6421CEKR2 Features

  • Dual 8.0 mOhm and 21 mOhm high-side switches.
  • 5.0 MHz SPI control and feedback.
  • Wide operating voltage range.
  • Integrated fault protection features.
  • Surface mount 54-SSOP exposed pad package.

MC08XS6421CEKR2 Applications

  • Automotive lighting and motor control.
  • Industrial load switching with diagnostics.
  • Power distribution in 12V systems.
  • Solenoid and relay driver applications.
  • General purpose high-side switching.

MC08XS6421CEKR2 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the operating voltage range of the MC08XS6421CEKR2?

Standard mode: 7.08V to 18V. Extended mode: 6.08V to 28V.

What package is the MC08XS6421CEKR2 available in?

54-HSOP or 54-SSOP (0.295", 7.50mm Width) Exposed Pad, surface mount.

What is the operating temperature range?

-40°C to 125°C.

How many outputs does the switch have?

4 outputs.

What is the maximum current per channel?

Channels 1 and 2: 11A. Channels 3 and 4: 5.5A.

What interface is used for control?

SPI with 5MHz clock frequency.

What fault protection features are included?

Current limiting (fixed), open load detection, and over-temperature protection.
