MBR4045PT MBR4045PT is a Schottky diode array with common cathode configuration, rated for 45V and 40A forward current, packaged in TO-247AD (TO-3P).
Mfr Part #:

MBR4045PT

Available from 1 distributors
Mfr Name: Taiwan Semiconductor
Taiwan Semiconductor
MBR4045PT is a Schottky diode array with common cathode configuration, rated for 45V and 40A forward current, packaged in TO-247AD (TO-3P).
✓ Total Stock: 3,357 pcs
$ Price Range: $1.35 - $3.87

MBR4045PT Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Components Technology Group, Inc. ✓
Non-Authorised Inventory information
3,357 pcs
On Request
3357 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

MBR4045PT Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Current
Diode Configuration
Lead Style
Mounting Type
Operating Temperature
Speed
Supplier Device Package
Tape & Reel
Technology
Voltage
View Similar Products (0)

MBR4045PT Description

Short technical summary and product information.

The MBR4045PT is a Schottky diode array from Taiwan Semiconductor, featuring a pair of common cathode Schottky diodes. It is designed for fast switching applications with a reverse voltage rating of 45V and a forward current of 40A. The typical forward voltage is 800 mV at 40A, and the reverse leakage current is 1 mA at 45V. The device operates over a temperature range of -55°C to 150°C. It is housed in a through-hole TO-247-3 package, also known as TO-247AD (TO-3P), suitable for high-power applications. The fast recovery speed (<500ns, >200mA) makes it suitable for power supply rectification and freewheeling diodes in switching converters.

MBR4045PT Quick Information

Product Type: Schottky Rectifier Diode Array
Canonical Name: MBR4045PT Schottky Diode Array, Common Cathode, 45V, TO-247AD
Subcategory: Rectifier Diode Arrays

MBR4045PT Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

MBR4045PT Estimated Pricing

Qty Low High
1+ $3.87 $3.87
10+ $2.53 $2.53
100+ $1.84 $1.84
500+ $1.44 $1.44
900+ $1.39 $1.39
1,800+ $1.35 $1.35

Estimated market price range - modelled values for guidance only, not live distributor offers.

MBR4045PT Features

  • Common cathode Schottky diode pair.
  • Rated for 45V reverse voltage.
  • Forward current of 40A typical.
  • Low forward voltage of 800 mV.
  • Through-hole TO-247AD package.

MBR4045PT Applications

  • Used in power supply rectification circuits.
  • Ideal for freewheeling diode applications.
  • Suitable for high-frequency switching converters.
  • Common in OR-ing diode circuits.

MBR4045PT FAQs

6 frequently asked questions generated from this part’s specifications.
What is the maximum reverse voltage?

45V

What is the forward current rating?

40A typical (based on forward voltage test condition)

What is the forward voltage?

800 mV typical at 40A

What is the reverse recovery time?

Less than 500ns at forward current above 200mA

What package is the MBR4045PT available in?

Through-hole TO-247-3 (TO-247AD)

What is the diode configuration?

1 pair common cathode
