MBI5042GP The Macroblock MBI5042GP is a 16-channel S-PWM LED display driver IC. It features 16-bit color depth and a constant output current range of 2-45mA per channel.
Mfr Part #:

MBI5042GP

Available from 2 distributors
Mfr Name: MBI
MBI
The Macroblock MBI5042GP is a 16-channel S-PWM LED display driver IC. It features 16-bit color depth and a constant output current range of 2-45mA per channel.
✓ Total Stock: 1,104 pcs

MBI5042GP Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Xingangxin ✓
Non-Authorised Inventory information
1,000 pcs
On Request
1000 pcs On Request 1 On Request On Request On Request On Request On Request
Smaxon Electronics ✓
Non-Authorised Inventory information
104 pcs
On Request
104 pcs On Request 1 On Request On Request 0804+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

MBI5042GP Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Mounting Type
Supply Voltage
Weight
View Similar Products (0)

MBI5042GP Description

Short technical summary and product information.

The MBI5042GP from Macroblock is a 16-channel S-PWM LED display driver IC designed for high-quality LED displays. It offers 16-bit color depth for precise color control and utilizes Scrambled-PWM technology to enhance the refresh rate.



This IC provides a constant output current range of 2-45mA per channel, with programmable output current gain via a 6-bit setting. It operates within a supply voltage range of 3.0V to 5.5V and supports a maximum data clock frequency of 30MHz. The device features staggered output delays to prevent current surges and a Smitt trigger input.



The MBI5042GP is available in a SSOP24L-150-0.64 package and is suitable for surface mount applications. Its design focuses on improving visual refresh rates and maintaining accurate current output for display applications.

MBI5042GP Quick Information

Product Type: LED Display Driver IC
Series: MBI5042
Canonical Name: MBI5042GP 16-Channel S-PWM LED Display Driver IC
Subcategory: Power Management - Specialized

MBI5042GP Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

MBI5042GP Features

  • 16-channel constant current LED driver.
  • 16-bit color depth PWM control.
  • Scrambled-PWM technology for refresh rate.
  • 6-bit programmable output current gain.
  • 3.0V to 5.5V supply voltage range.

MBI5042GP Applications

  • Driving LED displays.
  • High refresh rate applications.
  • Color accurate LED control.
  • General purpose LED driving.

MBI5042GP FAQs

7 frequently asked questions generated from this part’s specifications.
What is the supply voltage range of the MBI5042GP?

3.0V to 5.5V.

What package does the MBI5042GP come in?

SSOP24L-150-0.64 surface-mount package.

What is the output current range per channel?

2-45 mA.

What is the color depth of the MBI5042GP?

16-bit.

What is the maximum data clock frequency?

30 MHz.

What is the visual refresh rate?

3840 Hz at GCLK=4 MHz.

What is the output current gain resolution?

6-bit.
