| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
This AC DC converter from SL Power Electronics, part number MBAA40W-AG, offers a power output of 39W. It is designed for medical applications and features a linear type with chassis mount capability. The converter provides multiple outputs, including 5V, +12V, and -12V, with a current rating of 1A on the -12V output. Key features include adjustable output, remote sense, and universal input, making it versatile for various system designs.
The unit operates within a temperature range of 0°C to 70°C with derating. Its dimensions are 260.4mm in length, 101.6mm in width, and 63.5mm in height. The MBAA40W-AG is approved by CE, cURus, and TUV, indicating compliance with safety standards. It is listed as RoHS3 Compliant, has an MSL of 1, and is REACH Unaffected.
This converter is suitable for applications requiring stable power conversion with specific voltage and current requirements. Its robust design and approvals make it a reliable choice for medical equipment and other demanding environments.
The power output is 39W.
It is a linear AC DC converter.
It is designed for chassis mount.
The operating temperature is 0°C to 70°C with derating.
It is approved by CE, cURus, and TUV.
It is RoHS3 Compliant.
The Moisture Sensitivity Level is 1 Unlimited.
