MAX961EUA-T The Analog Devices MAX961EUA-T is a single general-purpose comparator with ultra-fast 4.5ns propagation delay. It operates from 1.8V to 5.5V and features 3.5mV internal hysteresis.
Mfr Part #:

MAX961EUA-T

Available from 1 distributors
Mfr Name: Analog Devices / Maxim Integrated
Analog Devices / Maxim Integrated
The Analog Devices MAX961EUA-T is a single general-purpose comparator with ultra-fast 4.5ns propagation delay. It operates from 1.8V to 5.5V and features 3.5mV internal hysteresis.
✓ Total Stock: 133 pcs
$ Price Range: $0.36

MAX961EUA-T Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Smaxon Electronics ✓
Non-Authorised Inventory information
133 pcs
On Request
133 pcs On Request 1 On Request On Request 15+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

MAX961EUA-T Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
CMRR, PSRR (Typ)
Current
Hysteresis
Lead Spacing
Mounting Type
Number of Elements
Operating Temperature
Output Type
Propagation Delay (Max)
Supplier Device Package
Tape & Reel
Type
Voltage
View Similar Products (0)

MAX961EUA-T Description

Short technical summary and product information.

The MAX961EUA-T from Analog Devices is a high-speed, low-power comparator optimized for single +3V or +5V operation. It offers an ultra-fast propagation delay of 4.5ns, making it suitable for high-speed applications. The input common-mode range extends 100mV Beyond-the-Rails, and the outputs are TTL/CMOS-compatible.



This comparator features 3.5mV of internal hysteresis for clean switching and operates over a wide voltage range of 1.8V to 5.5V. The device consumes a low supply current of 5mA per comparator. It is available in a space-saving 8-pin uMAX package, suitable for surface mount applications.



Key applications include single 3V/5V systems, portable and battery-powered devices, threshold detectors, GPS receivers, line receivers, zero-crossing detectors, and high-speed sampling circuits.

MAX961EUA-T Quick Information

Product Type: Comparator
Canonical Name: MAX961EUA-T Single General Purpose Comparator
Subcategory: General Purpose

MAX961EUA-T Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

MAX961EUA-T Estimated Pricing

Qty Low High
1+ $0.36 $0.36

Estimated market price range - modelled values for guidance only, not live distributor offers.

MAX961EUA-T Features

  • Ultra-fast 4.5ns propagation delay.
  • 3.5mV internal hysteresis for clean switching.
  • Operates from 1.8V to 5.5V single supply.
  • CMOS, Complementary, TTL compatible outputs.
  • Available in 8-uMAX surface mount package.

MAX961EUA-T Applications

  • Ideal for single 3V/5V systems.
  • Suitable for portable battery-powered devices.
  • Used in threshold detectors and discriminators.
  • Applicable for GPS receivers and line receivers.
  • Useful for zero-crossing detectors.

MAX961EUA-T FAQs

5 frequently asked questions generated from this part’s specifications.
What is the propagation delay of the MAX961EUA-T comparator?

The propagation delay is 4.5ns.

What is the hysteresis of the MAX961EUA-T comparator?

The hysteresis is 3.5mV.

What is the operating voltage range for the MAX961EUA-T?

The operating voltage is 1.8V to 5.5V.

What is the operating temperature range for the MAX961EUA-T?

The operating temperature is -40°C to 85°C.

What package is the MAX961EUA-T comparator supplied in?

The MAX961EUA-T is supplied in an 8-uMAX/uSOP package.
