APX810-26SAG-7
Diodes Incorporated
The Diodes Incorporated APX810-26SAG-7 is a supervisor IC designed for microprocessor power monitoring. It features a 2.63V threshold and an active high reset output.
| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
401,778 pcs
|
401778 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Mounting Type | |
| Number of Voltages Monitored | |
| Operating Temperature | |
| Output | |
| Reset | |
| Reset Timeout | |
| Supplier Device Package | |
| Type | |
| Voltage |
The MAX810REUR-T is a microprocessor supervisory circuit designed to monitor power supplies in digital systems. It provides a reset signal when the VCC supply voltage falls below a preset threshold, ensuring system stability.
Key electrical specifications include a nominal operating voltage of 2.63V and a minimum reset timeout of 140ms. The device features an active-high, push-pull output and monitors a single voltage channel. It operates over a temperature range of -40°C to 85°C.
This supervisor IC is housed in a compact SOT-23-3 surface-mount package, making it suitable for space-constrained applications. Its simple reset/power-on reset functionality eliminates the need for external components, contributing to circuit reliability and cost-effectiveness.
Applications include critical μP and μC power monitoring, portable and battery-powered equipment, and automotive systems.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.75 | $0.75 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The nominal voltage threshold is 2.63V.
The minimum reset timeout is 140ms.
Operating temperature range is -40°C to 85°C (TA).
The package is SOT-23-3 (TO-236-3, SC-59, SOT-23-3).
Output type is Push-Pull, Totem Pole.
Reset polarity is Active High.
Mounting type is Surface Mount.
