| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,265 pcs
|
2265 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
160 pcs
|
160 pcs | On Request | 1 | On Request | On Request | On Request | On Request | 2026-02-23 21:33:16 |
| Category | |
| Manufacturer Name | |
| Filter Order | |
| Filter Type | |
| Frequency | |
| Lead Spacing | |
| Mounting Type | |
| Number of Filters | |
| Operating Voltage | |
| Storage Temperature | |
| Supplier Device Package | |
| Tape & Reel | |
| Voltage |
The MAX7410EUA+ is a 5th-order, low-pass, switched-capacitor filter (SCF) from Analog Devices / Maxim Integrated. It is designed for applications requiring a Butterworth response, offering a maximally flat passband. This device operates from a single +5V supply and supports clock-tunable corner frequencies ranging from 1Hz to 15kHz.
Key features include low power consumption, drawing only 1.2mA in operating mode and reducing to 0.2µA in shutdown mode. It also offers a low output offset of ±4mV. The MAX7410EUA+ is ideal for low-power post-DAC filtering and anti-aliasing applications.
This filter is available in an 8-pin µMAX/uSOP package and is designed for surface mount applications. The fixed Butterworth response simplifies design tasks by focusing on clock frequency selection.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.74 | $1.74 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The MAX7410EUA+ is a 5th-order, Butterworth, low-pass, switched-capacitor filter.
The cutoff frequency for the MAX7410EUA+ is 15kHz.
The MAX7410EUA+ operates from a voltage supply range of 4.5V to 5.5V.
The MAX7410EUA+ is available in an 8-uMAX/uSOP package.
The MAX7410EUA+ is designed for surface mount applications.
The MAX7410EUA+ draws 1.2mA of supply current in operating mode.
The shutdown current for the MAX7410EUA+ is 0.2µA.
