| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
7 pcs
|
7 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Channels | |
| Lead Spacing | |
| Lead Style | |
| Mounting Type | |
| Package / Case | |
| SVHC Present | |
| Tape & Reel | |
| Voltage Supply |
The MAX5949BESA+ is a hot swap controller IC manufactured by Analog Devices/Maxim Integrated. It is designed to manage power in systems operating at -48V, with a supported voltage range of -80V to -20V.
This controller features a supply current of 700µA and operates within a temperature range of -40°C to 85°C. It is housed in a compact 8-SOIC package and is suitable for surface mount applications.
The device includes programmable features such as Auto Retry, Circuit Breaker, Latched Fault, OVP (Overvoltage Protection), and UVLO (Undervoltage Lockout), enhancing system reliability and protection. It is designed for single-channel operation.
Packaging details include a Tape & Reel (TR) format, indicating it is supplied on reels for automated assembly processes. The component is identified by part number MAX5949BESA+.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.31 | $1.31 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The device supports supply voltages of -20V, -48V, and -80V.
The package is 8-SOIC (surface mount).
The operating temperature range is -40°C to 85°C.
The supply current is 700µA.
The device has 1 channel.
The mounting type is surface mount.
