| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
33,481 pcs
|
33481 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
1,177 pcs
|
1177 pcs | On Request | 1 | On Request | On Request | 1408+ | On Request | On Request | |
|
918 pcs
|
918 pcs | On Request | 1 | On Request | On Request | 617 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Bandwidth | |
| Lead Spacing | |
| Lead Style | |
| Number of Circuits | |
| Operating Temperature | |
| Output Type | |
| Supply Current | |
| Supply Voltage | |
| Tape & Reel |
The MAX4016ESAT from Analog Devices is a high-speed, single-supply operational amplifier featuring Rail-to-Rail outputs. This device is suitable for video applications, offering a wide bandwidth of 150MHz.
It operates over a supply voltage range of 3.15V to 11V and has a typical supply current of 5.5mA. The amplifier provides a typical output current of 120mA per channel and a low input bias current of 5.4µA. The input offset voltage is typically 4mV.
Packaged in an 8-SOIC (Small Outline Integrated Circuit) package, the MAX4016ESAT is designed for industrial temperature ranges from -40°C to 85°C. Its construction utilizes plastic/epoxy for the package body material and tin-lead for terminal finish.
This operational amplifier is characterized by its two circuits, providing versatile functionality for various electronic designs requiring high-speed signal amplification.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The MAX4016ESAT operates from a single supply of 3.15 V to 11 V, or a dual supply of ±1.575 V to ±5.5 V.
The -3dB bandwidth is 150 MHz.
The operating temperature range is -40°C to 85°C.
The output type is rail-to-rail.
The MAX4016ESAT has 2 circuits.
The MAX4016ESAT is available in an 8-SOIC package.
