MAX20730EPL+T The MAX20730EPL+T is a highly efficient, integrated step-down switching regulator from Analog Devices / Maxim Integrated. It operates from a 4.5V to 16V input and delivers up to 25A.
Mfr Part #:

MAX20730EPL+T

Available from 3 distributors
Mfr Name: Analog Devices / Maxim Integrated
Analog Devices / Maxim Integrated
The MAX20730EPL+T is a highly efficient, integrated step-down switching regulator from Analog Devices / Maxim Integrated. It operates from a 4.5V to 16V input and delivers up to 25A.
✓ Total Stock: 23,705 pcs
$ Price Range: $1.08

MAX20730EPL+T Available from 3 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Optech Co.,Limited ✓
Non-Authorised Inventory information
10,181 pcs
On Request
10181 pcs On Request 1 On Request On Request 20+ On Request On Request
Romaks Technologies ✓
Non-Authorised Inventory information
10,044 pcs
On Request
10044 pcs On Request 1 On Request On Request On Request On Request On Request
Xingangxin ✓
Non-Authorised Inventory information
3,480 pcs
On Request
3480 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

MAX20730EPL+T Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Current
Frequency
Function
Industrial Grade
Mounting Type
Number of Outputs
Operating Temperature
Output Configuration
Output Type
Supplier Device Package
Synchronous Rectifier
Tape & Reel
Topology
Voltage
View Similar Products (0)

MAX20730EPL+T Description

Short technical summary and product information.

The MAX20730EPL+T is a fully integrated, highly efficient switching regulator designed for applications operating from 4.5V to 16V, requiring up to 25A load. This single-chip solution offers a compact, high-efficiency power delivery with precise output voltages and excellent transient response, suitable for networking, datacom, and telecom equipment.



Key features include a PMBus-compliant interface for telemetry and power management, enabling voltage, current, and temperature reporting. The device incorporates protection features such as cycle-by-cycle overcurrent protection, overtemperature protection, and input undervoltage lockout for enhanced reliability. It also includes differential remote sense with open-circuit detection.



The regulator supports adjustable output voltages from 0.65V to 5.5V and operates with a switching frequency between 400kHz and 900kHz. It is available in a 15-VFQFN, FCQFN package suitable for surface mounting.



With a peak efficiency of 90.8% (at 12V input, 1V output) and the ability to support load-step transients up to 300A/μs, the MAX20730EPL+T provides robust performance for demanding applications.

MAX20730EPL+T Quick Information

Product Type: DC DC Switching Regulator
Canonical Name: MAX20730EPL+T Integrated Step-Down Switching Regulator with PMBus
Subcategory: PMIC - Voltage Regulators

MAX20730EPL+T Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

MAX20730EPL+T Estimated Pricing

Qty Low High
1+ $1.08 $1.08

Estimated market price range - modelled values for guidance only, not live distributor offers.

MAX20730EPL+T Features

  • Integrated step-down switching regulator.
  • Input voltage range 4.5V to 16V.
  • Output current up to 25A.
  • Adjustable output voltage 0.65V to 5.5V.
  • PMBus interface for telemetry and control.

MAX20730EPL+T Applications

  • Ideal for networking equipment.
  • Suitable for datacom applications.
  • Used in telecom power systems.
  • Point-of-load voltage regulation.
  • Supports servers and storage systems.

MAX20730EPL+T FAQs

7 frequently asked questions generated from this part’s specifications.
What is the input voltage range of the MAX20730EPL+T?

The input voltage range is 4.5V to 16V.

What is the output voltage range?

The output voltage is adjustable from 0.65V to 5.5V.

What is the operating temperature range?

The operating junction temperature range is -40°C to 125°C.

What is the switching frequency?

The switching frequency is programmable from 400kHz to 900kHz.

What is the peak efficiency?

The peak efficiency is 90.8% at VDDH = 12V and VOUT = 1V.

What protection features does the MAX20730EPL+T include?

It includes positive and negative cycle-by-cycle overcurrent protection, overtemperature protection, and input undervoltage lockout.

What package is the MAX20730EPL+T available in?

It is available in a 15-VFQFN or FCQFN package, specifically the 15-FCQFN (6x4.15) supplier device package.
