MAX1697TEUT-T The MAX1697TEUT-T is an inverting charge pump voltage regulator from Analog Devices Inc./Maxim Integrated. It operates with an input voltage range of 1.4V to 5.5V and provides an output current of up to 60mA.
Mfr Part #:

MAX1697TEUT-T

Available from 1 distributors
Mfr Name: MAX
MAX
The MAX1697TEUT-T is an inverting charge pump voltage regulator from Analog Devices Inc./Maxim Integrated. It operates with an input voltage range of 1.4V to 5.5V and provides an output current of up to 60mA.
✓ Total Stock: 810 pcs

MAX1697TEUT-T Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Husky International Electronic ✓
Non-Authorised Inventory information
810 pcs
On Request
810 pcs On Request 1 On Request On Request N/A On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

MAX1697TEUT-T Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Mounting Type
Output Current
Output Voltage
Tape & Reel
View Similar Products (0)

MAX1697TEUT-T Description

Short technical summary and product information.

The MAX1697TEUT-T is an inverting charge pump voltage regulator manufactured by Analog Devices Inc./Maxim Integrated. This component is designed for applications requiring a negative output voltage derived from a positive input. It features a wide input voltage range from 1.4V to 5.5V, making it versatile for various power supply designs.



The device can deliver an output current of up to 60mA with a switching frequency of 125kHz. The output voltage configuration is specified as -Vin, 2Vin, indicating its charge pump topology. The operating temperature range is from -40°C to 85°C (TA), suitable for a broad spectrum of environmental conditions.



Packaged in a compact SOT-23-6 surface mount package, the MAX1697TEUT-T is ideal for space-constrained applications. Its surface mount design facilitates automated assembly processes. The component is classified under Voltage Regulators - DC DC Switching Regulators within the Power Management (PMIC) category.

MAX1697TEUT-T Quick Information

Product Type: Inverting Charge Pump
Series: MAX1697
Canonical Name: Analog Devices Inc./Maxim Integrated MAX1697TEUT-T Inverting Charge Pump
Subcategory: Power Management (PMIC)

MAX1697TEUT-T Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

MAX1697TEUT-T Features

  • Inverting charge pump voltage regulator.
  • Input voltage range: 1.4V to 5.5V.
  • Output current up to 60mA.
  • Switching frequency of 125kHz.
  • Surface mount SOT-23-6 package.

MAX1697TEUT-T Applications

  • Suitable for negative voltage generation.
  • Ideal for low power applications.
  • Compact designs requiring small footprint.
  • Wide input voltage range flexibility.

MAX1697TEUT-T FAQs

7 frequently asked questions generated from this part’s specifications.
What is the input voltage range for the MAX1697TEUT-T?

The input voltage range is from 1.4V to 5.5V.

What is the maximum output current of the MAX1697TEUT-T?

The maximum output current is 60mA.

What is the switching frequency of the MAX1697TEUT-T?

The switching frequency is 125kHz.

What is the operating temperature range for the MAX1697TEUT-T?

The operating temperature range is -40°C to 85°C.

What package type is the MAX1697TEUT-T available in?

The MAX1697TEUT-T is available in a SOT-23-6 surface mount package.

What is the RoHS status of the MAX1697TEUT-T?

The RoHS status is RoHS3 Compliant.

What is the Moisture Sensitivity Level (MSL) for the MAX1697TEUT-T?

The Moisture Sensitivity Level (MSL) is 1 Unlimited.
