The MINMAX MAU412 is a 1W encapsulated DC-DC converter housed in an industry-standard SIP-7 package. It is specifically engineered for medical and safety-critical applications, offering robust I/O isolation of 3000VAC with reinforced insulation, rated for 300Vrms working voltage.
This series complies with medical EMC standards (EN 55011, EN 60601-1-2) and medical safety standards (IEC/EN/ANSI/AAMI ES60601-1 3.2 Edition for 1xMOPP & 2xMOOP). It also meets UL/cUL/IEC/EN 62368-1 safety approvals and carries CE marking. The converter includes a Risk Management Report according to ISO 14971.
Available with 5VDC or 12VDC input, and various single or dual output voltages, the MAU412 provides design flexibility. It operates across a wide ambient temperature range of -25℃ to +85℃. Its compact size, strong isolation, and regulatory compliance make it suitable for medical instrumentation, monitoring systems, and patient-connected devices.
The MAU412 provides 1W output power.
The MAU412 provides 3000VAC I/O isolation.
The MAU412 operates from -25°C to +85°C.
The MAU412 is available in a SIP-7 through-hole package.
Output voltage options include 5V, 12V, 15V, ±5V, ±12V, and ±15V DC.
The MAU412 has a typical efficiency of up to 75%.
Yes, the MAU412 features short-term short circuit protection.
