| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
104 pcs
|
104 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Halogen Free | |
| Mounting Type | |
| Operating Temperature | |
| Storage Temperature | |
| Voltage |
The MASWSS0181 is a GaAs PHEMT MMIC single pole double throw (SPDT) high power switch designed for applications requiring high power, low control voltage, low insertion loss, and high isolation. It operates from DC to 3.0 GHz with a low operating voltage of 2.5 V.
Key electrical specifications include a typical insertion loss of 0.40 dB at 1 GHz and a typical isolation of 20 dB at 2 GHz. The switch exhibits harmonics of less than -67 dBc at +34 dBm and 1 GHz. It is fabricated using a 0.5 micron GaAs pHEMT process.
The device is housed in a lead-free SOT-26 package with 100% matte tin plating over copper and a halogen-free mold compound, making it 260°C reflow compatible. The MASWSS0181 is suitable for applications such as GSM and DCS handset systems, connecting separate transmit and receive functions to a common antenna, and other general-purpose applications up to 3 GHz.
Absolute maximum ratings include an input power of 38 dBm (0.5 - 3 GHz, 2.5 V Control) and operating voltages up to ±8.5 V. The operating temperature range is -40°C to +85°C.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.87 | $1.87 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The typical insertion loss of the MASWSS0181 at 1 GHz is 0.40 dB.
The typical isolation of the MASWSS0181 at 2 GHz is 20 dB.
The MASWSS0181 has a low voltage operation of 2.5 V.
The operating temperature range for the MASWSS0181 is -40°C to +85°C.
The MASWSS0181 is supplied in a lead-free SOT-26 package.
The MASWSS0181 is RoHS3 Compliant.
The Moisture Sensitivity Level (MSL) for the MASWSS0181 is 1 Unlimited.
