| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Input Voltage | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| SVHC Present | |
| Type | |
| Voltage |
The Bel Power Solutions MAP110-4200 is an open-frame AC/DC converter designed for industrial applications. It features a universal input voltage range of 85-264 VAC and provides four outputs: 12V, 24V, -12V, and 5V, with a combined output power of 80W (110W forced air).
Key electrical specifications include line regulation of 0.1%, load regulation of 0.5%, and ripple and noise of 1%. The unit boasts an efficiency of 80% and features like adjustable output, remote sense, and universal input. It is designed for chassis mounting and has dimensions of 7.00" L x 4.30" W x 1.97" H.
This power supply operates within a temperature range of 0°C to 70°C with derating. It meets various approval agency standards including CB, cCSAus, and CE. The MAP110-4200 series is known for its reliability, with an MTBF greater than 134,000 hours.
The input voltage range is 85-264 VAC.
The MAP110-4200 provides four outputs: 12VDC, 24VDC, -12VDC, and 5VDC.
The total output power is 80W, or 110W with forced air cooling.
The operating temperature range is 0°C to 70°C, with derating.
The MAP110-4200 uses chassis mounting.
The product is listed as RoHS3 Compliant.
