The MACOM Technology Solutions MAFL-011014 is a low-cost, surface-mount diplex filter unit designed for CATV, DTV, and DBS applications. This filter features a 75 Ohm impedance and is compliant with RoHS3 standards.
Key electrical specifications include an insertion loss of 0.5 dB for the 5-65 MHz band and 1.2 dB for the 88-1002 MHz band. The filter rejection is rated at a minimum of 50 dB for the 5-65 MHz band and 55 dB for the 88-1002 MHz band. Return loss is a minimum of 15 dB for 5-65 MHz and 20 dB for 88-1002 MHz, with isolation at a minimum of 50 dB across both bands.
The operating temperature range for this unit is -40°C to +85°C, with a storage temperature range of the same. It has a maximum DC current rating of 30mA and a maximum RF power rating of 250mW. The MAFL-011014 is supplied on a 330mm reel with 200 pieces per reel.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.34 | $0.34 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The impedance is 75 ohms.
The typical insertion loss is 0.5 dB.
The minimum filter rejection is 55 dB.
The operating temperature range is -40°C to +85°C.
It is packaged in an SMT unit.
The maximum DC current is 30 mA.
RoHS compliance status is unverified.
