The P-DUKE Technology, Inc. MAD30US7P5B is an enclosed AC DC converter designed for versatile power supply needs. It features a universal input voltage range of 90-264 VAC and a maximum power output of 1200W.
This converter provides five distinct output voltages: 24V, 48V, 12V, 24V, and 24V, with corresponding output currents of 10A, 5A, 20A, 10A, and 20A respectively. It boasts an efficiency of 88.5% and offers features such as adjustable output, load sharing, PFC, remote on/off, remote sense, and a standby output.
The MAD30US7P5B is suitable for applications in ITE (Commercial) and Medical sectors. It has an isolation voltage of 4 kV and operates within a temperature range of -30°C to 70°C with derating. The unit is chassis mountable and has dimensions of 250.0mm x 127.0mm x 41.0mm.
Compliance standards include 60601-1 and 62368-1. The product is ROHS3 Compliant and REACH Unaffected. It is packaged in a box.
The input voltage range is 90 to 264 VAC.
The NMP1K2-HKEHHH-05 has 5 outputs.
The output voltages are 24V, 48V, 12V, 24V, and 24V.
The maximum power output is 1200W.
The operating temperature range is -30°C to 70°C with derating.
The dimensions are 250.0mm x 127.0mm x 41.0mm.
It meets standards 60601-1 and 62368-1.
