| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
786 pcs
|
786 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Attenuation Value | |
| Frequency Range | |
| Halogen Free | |
| Impedance | |
| Lead Spacing | |
| Mounting Type | |
| Number of Bits | |
| Tape & Reel |
The MACOM Technology Solutions MAATCC0005 is a 6-bit digital attenuator designed for applications requiring accuracy, speed, and low power consumption. It provides a total attenuation range of 31.5 dB with a minimum step size of 0.5 dB.
This attenuator operates over a frequency range of DC to 2.0 GHz and maintains a 50 ohm impedance. Key electrical specifications include insertion loss typically between 3.1 dB and 4.2 dB, and an attenuation accuracy of ±(0.3 + 4% of atten.). It features a TTL driver for digital control.
The device is housed in a 24-SOIC wide body, plastic surface mount package. It is compatible with 260°C reflow soldering and is RoHS compliant, lead-free, and halogen-free.
Ideal for various RF applications, the MAATCC0005 offers reliable performance in a compact SMT package.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The MAATCC0005 offers a maximum attenuation value of 31.5 dB.
The MAATCC0005 operates over a frequency range from DC to 2.0 GHz.
The impedance of the MAATCC0005 is 50 Ohms.
The MAATCC0005 is supplied in a 24-SOIC (0.295", 7.50mm Width) package.
Yes, the MAATCC0005 is RoHS3 Compliant.
The Moisture Sensitivity Level (MSL) for the MAATCC0005 is 1.
Yes, the MAATCC0005 is available in tape and reel packaging.
