The MA4SW410B-1 is a Silicon SP4T PIN Diode Switch with an integrated bias network, manufactured by MACOM Technology Solutions. This device utilizes MACOM's HMIC™ process, offering broad bandwidth specified up to 18 GHz and usable up to 26 GHz. It is designed for applications requiring high isolation to insertion loss ratios, such as multi-band ECM, Radar, and instrumentation control circuits.
The switch exhibits low insertion loss, with typical values of 0.8 dB at 6 GHz, 1.0 dB at 12 GHz, and 1.4 dB at 18 GHz. Isolation is rated at 35 dB typical at 18 GHz. Input return loss is typically 10 dB at 6 GHz and 18 GHz, and 15 dB at 12 GHz. Switching speeds of 80 ns can be achieved with a standard +5 V / -5 V, TTL controlled PIN diode driver.
Constructed as a fully monolithic, glass-encapsulated chip, the MA4SW410B-1 features large bond pads for low inductance ribbon bonds and gold backside metallization for chip bonding. The operating temperature range is -65°C to 125°C. It is supplied in a Die package, with a Gel Pack option available for ordering.
This RoHS3 compliant component is suitable for various high-frequency applications where reliable switching performance is critical.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.75 | $0.75 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The typical insertion loss at 18 GHz is 1.4 dB.
The typical isolation at 18 GHz is 30 dB.
The operating temperature range is -65°C to 125°C.
The typical switching speed at 10 GHz is 80 ns.
The frequency range is specified up to 18 GHz and usable up to 26 GHz.
The MA4SW410B-1 is a SP4T broadband PIN diode switch with an integrated bias network.
