| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
5,800 pcs
|
5800 pcs | On Request | 1 | On Request | On Request | 21+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Capacitance @ Vr, F | |
| Diode Type | |
| Mounting Type | |
| Operating Temperature | |
| Q @ Vr, F | |
| Tape & Reel | |
| Voltage |
The MA46H120 is a varactor diode designed for RF and microwave tuning applications. It is manufactured by MACOM Technology Solutions and features a flip-chip GaAs construction. The diode has a breakdown voltage of at least 20V under a test condition of IR = 10μA, and a maximum reverse leakage current of 100nA at VR = 14V. Its design allows for variable capacitance controlled by reverse bias voltage, making it suitable for voltage-controlled oscillators and RF filters.
This device is packaged in a flip-chip GaAs form factor, enabling compact and high-performance integration in electronic circuits. Its electrical characteristics are critical for applications requiring precise tuning and low leakage currents. The MA46H120 is used in RF communication systems, phase shifters, and voltage-controlled oscillators where stable and predictable varactor behavior is essential.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The MA46H120 has a minimum breakdown voltage of 20V under the test condition IR = 10μA.
The maximum reverse leakage current is 100nA at VR = 14V.
