| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2 pcs
|
2 pcs | On Request | 1 | On Request | On Request | N/A | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Style | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Type | |
| Current Rating (Amps) | |
| Flange Feature | |
| Insulation Material | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Operating Temperature | |
| Shell Material, Finish | |
| Shell Size, Connector Layout | |
| Termination |
This ITT Cannon M83513/10-F01CP is a Micro-D connector assembly with 37 positions arranged in 2 rows. It is designed for signal applications and offers a current rating of 3A. The connector features a durable aluminum shell with a yellow chromate plated cadmium finish and Liquid Crystal Polymer (LCP) insulation.
The connector is suitable for panel mount, through-hole, right-angle applications. It includes a mating side female screwlock feature for secure connection. The termination style is solder, with gold plating on the contacts providing a thickness of 50.0µin (1.27µm).
Operating within a temperature range of -55°C to 125°C, this connector is built for demanding environments. The shell size and connector layout are specified as 0.050 Pitch x 0.043 Row to Row, characteristic of Micro-D form factors.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.00 | $1.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The ITT Cannon M83513/10-F01CP connector has 37 positions.
The current rating for the M83513/10-F01CP connector is 3A.
The M83513/10-F01CP connector uses Panel Mount, Through Hole, Right Angle mounting.
The contact finish on the M83513/10-F01CP connector is Gold.
The operating temperature range for the M83513/10-F01CP connector is -55°C to 125°C.
