| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
126 pcs
|
126 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Connector Type | |
| Contact Finish | |
| Contact Finish - Mating | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Type | |
| Fastening Type | |
| Halogen Free | |
| Industrial Grade | |
| Insulation Color | |
| Insulation Height | |
| Lead Spacing | |
| Lead Style | |
| Mated Stacking Heights | |
| Material Flammability Rating | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| SVHC Present | |
| Style | |
| Termination | |
| Voltage Rating |
The Harwin M80-8500442 is a 4-position (2+2) female receptacle connector from the Datamate L-Tek series, designed for board-to-board or cable-to-board applications. This through hole connector features a 2.00mm pitch and 2.00mm row spacing, with a straight solder termination having a 3.00mm contact length.
The connector is rated for up to 3.3A per contact (single contact, 25°C) and has an operating temperature range of -55°C to 125°C. The mating contacts receive a gold finish, while the termination area is tin-plated. The locking ramp fastening type ensures secure mating with compatible male plug connectors. The insulation material is rated UL94 V-0, and the housing is black.
Mated stacking heights of 7.23mm and 7.85mm are supported. The connector is suitable for high-reliability applications requiring a compact 2mm pitch format. It is RoHS3 compliant (unverified) and has MSL Level 1 rating (unverified).
| Qty | Low | High |
|---|---|---|
| 1+ | $3.74 | $3.74 |
| 32+ | $2.93 | $2.93 |
| 128+ | $2.65 | $2.65 |
| 512+ | $2.41 | $2.41 |
| 1,024+ | $2.29 | $2.29 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It has 4 positions arranged in 2 rows (2+2).
The pitch is 2.00mm (0.079").
Maximum current is 3.3A per contact when one contact is loaded at 25°C ambient, derating to 2.6A at 85°C. With all contacts loaded, it is 3.0A at 25°C and 2.2A at 85°C.
The voltage rating is 800V (unverified, typical for series).
It uses through hole mounting with straight solder terminations.
The operating temperature range is -55°C to +125°C.
It features a locking ramp for secure mating.
