The Harwin M80-7055105 is a 51-position, 3-row female receptacle connector from the Datamate 3-Row (Legacy) series. It features a 2.00mm pitch with 2.00mm row spacing and is designed for free hanging (in-line) mounting. Termination is via crimp for 24-28 AWG discrete wires, using female socket contacts with gold plating (0.30µm thickness). The connector is equipped with floating jackscrews with a hexagonal socket head for secure mating and easy installation.
Electrical ratings include a maximum current per contact of 3.3A at 25°C ambient for a single loaded contact, derating to 2.6A at 85°C. When all contacts are loaded, the maximum current is 3.0A at 25°C and 2.2A at 85°C. The maximum working voltage is 120V DC or AC peak, with a voltage proof of 360V. Initial contact resistance is 20 mΩ maximum, and insulation resistance is at least 1000 MΩ initially.
This connector is suited for high-density board-to-wire interconnect applications requiring reliable performance in demanding environments. The complete kit includes the triple-row straight cable housing and 51 straight signal contacts, making it ready for assembly.
| Qty | Low | High |
|---|---|---|
| 1+ | $33.38 | $33.38 |
| 12+ | $28.00 | $28.00 |
| 108+ | $23.98 | $23.98 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
51 positions arranged in 3 rows.
2.00mm pitch with 2.00mm row spacing.
3.3A max per contact (single contact at 25°C), 2.6A at 85°C. When all contacts are loaded, 3.0A at 25°C, 2.2A at 85°C.
Maximum working voltage is 120V DC or AC peak, with a voltage proof of 360V DC or AC peak.
Free hanging (in-line) mounting with crimp termination.
24-28 AWG discrete wires.
Gold plating with 0.30µm (11.8µin) thickness.
