M80-5611405 This is a 14-position, 2.00mm pitch male header connector from Harwin's Datamate M80 series. It features crimp termination, gold contacts, and jackscrews for secure mating.
Mfr Part #:

M80-5611405

Available from 1 distributors
Mfr Name: Harwin Inc.
Harwin Inc.
This is a 14-position, 2.00mm pitch male header connector from Harwin's Datamate M80 series. It features crimp termination, gold contacts, and jackscrews for secure mating.
✓ Total Stock: 20 pcs
$ Price Range: $12.06 - $18.70

M80-5611405 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
ADI/AAR OEM Supply ✓
Non-Authorised Inventory information
20 pcs
On Request
20 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

M80-5611405 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Cable Termination
Color
Connector Type
Contact Finish
Contact Finish Thickness
Contact Type
Features
Lead Spacing
Lead Style
Mounting Type
Number of Positions
Number of Rows
Pitch
Row Spacing
Termination Style
Wire Gauge
Wire Type
View Similar Products (0)

M80-5611405 Description

Short technical summary and product information.

The M80-5611405 is a 14-position male header connector from Harwin's Datamate M80 series, designed for free hanging (in-line) mounting with crimp termination. It features a 2.00mm pitch and 2 rows of male pins with gold contacts (0.25µm thickness). The connector is rated for currents up to 3.3A per contact (single contact loaded at 25°C) and accepts 24-28 AWG discrete wires. Jackscrews are included for secure mating. This connector is suitable for high-density packaging in electronic equipment where reliable connections are required. The black housing and gold plating provide durability and corrosion resistance.

M80-5611405 Quick Information

Product Type: Header Connector
Series: M80
Canonical Name: Harwin M80-5611405 14 Position 2.00mm Pitch Male Header Connector
Subcategory: Free Hanging, Panel Mount

M80-5611405 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

M80-5611405 Estimated Pricing

Qty Low High
1+ $18.70 $18.70
10+ $15.90 $15.90
25+ $14.90 $14.90
50+ $14.19 $14.19
100+ $13.51 $13.51
250+ $12.67 $12.67
500+ $12.06 $12.06

Estimated market price range - modelled values for guidance only, not live distributor offers.

M80-5611405 Features

  • 14-position male header with 2.00mm pitch.
  • Crimp termination for 24-28 AWG wires.
  • Gold-plated contacts for reliable connections.
  • Includes jackscrews for secure mating.
  • Rated up to 3.3A per contact.

M80-5611405 Applications

  • Used in high-density electronic packaging.
  • Suitable for cable-to-cable interconnections.
  • Ideal for applications requiring secure latching.
  • Common in industrial control systems.

M80-5611405 FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does the M80-5611405 have?

14 positions.

What is the pitch of this connector?

2.00mm.

What is the current rating of the M80-5611405?

Up to 3.3A per contact when one contact is loaded at 25°C, derated to 2.2A per contact when all contacts are loaded at 85°C.

What is the mounting type?

Free hanging (in-line) with crimp termination.

What wire gauge does this connector accept?

24-28 AWG discrete wires.

What contact finish does the M80-5611405 have?

Gold plating with 0.25µm thickness.

Does this connector have any locking features?

Yes, it includes jackscrews for secure mating.
