The M80-5000422 is a 4-position (2+2) male header from the Harwin Datamate J-Tek series, designed for high-reliability board-to-board or cable-to-board interconnections. It features a 2.00mm pitch with 2.00mm row spacing, and is configured as a through hole, straight (vertical) mount connector with solder termination.
The connector is fully shrouded with 4 walls and includes threaded jackscrews for secure mating. It is fitted with male pin contacts made of phosphor bronze, with a gold finish on the mating area and tin-lead finish on the termination area. The contact finish thickness is 29.5 µin (0.75 µm).
Electrical ratings include a maximum current of 3.0 A per contact at 25°C (3.3 A single contact at 25°C) and a voltage rating of 120 V. The operating temperature range is -55°C to 125°C. The insulation is made of glass-filled polyphenylene sulfide (PPS) with a UL94 V-0 flammability rating, and the insulator is black.
The connector features a keying slot and mating flange for polarization and alignment. It is intended for use in applications requiring reliable, high-density connections in industrial, automotive, and other demanding environments.
| Qty | Low | High |
|---|---|---|
| 1+ | $10.02 | $10.02 |
| 18+ | $8.17 | $8.17 |
| 108+ | $7.20 | $7.20 |
| 504+ | $6.46 | $6.46 |
| 1,008+ | $6.15 | $6.15 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
It has 4 positions (2+2), all loaded.
The pitch is 2.00mm (0.079 inches).
The voltage rating is 120V.
The maximum current rating is 3.0A for all contacts at 25°C ambient, and 3.3A for a single contact at 25°C.
It uses through hole mounting.
The operating temperature range is -55°C to 125°C.
The mating area has a gold finish with a thickness of 29.5 µin (0.75 µm).
